The FARO Laser Tracker X V2 adds higher accuracy and expanded temperature range. The FARO Laser TrackerX V2 is a portable contact measurement system which uses laser technology to accurately measure large parts and machinery across a wide range of industrial applications. It has a 230-foot range, achieves 0.001” accuracy, and runs in two-distance measurement modes, making it the most accurate and flexible Laser Tracker system.

• XtremeADM: Acquires the beam instantly with fast, highaccuracy absolute distance measurement (ADM).
• SelfComp: Automatically compensates to quickly ensure high accuracy
• Full Featured Standard Equipment: Integrated precision level and weather station.
• Smart Warm-Up: Newly expanded operating temperature, along with active thermal compensation make it ready for all environments
• Versatile Mounting Options: Mounts vertically, horizontally or upside down, providing versatility in tight or congested shop areas
• Spherically Mounted Retroreflectors: Certified precision probes

The system measures 3D coordinates with its laser by following a mirrored spherical probe. With high accuracy angular encoders and XtremeADM — Absolute Distance Measurement, it reports the 3D position of the probe in real-time.

It enables manufacturing, service, engineering, and quality control professionals to measure and align large parts, assemblies, and machinery on-site, in-process, or wherever it’s most efficient and cost-effective. With the exclusive technology in the X and Xi V2, the FARO Tracker is even more battle-ready for your facility’s most extreme measurement challenges.

System Specifications

Head size: 280 x 554 mm (11 x 21.8 in)
Head weight: 20 kg (44 lbs)
Controller size: 160 x 180 x 280 mm (6 x 7 x 11 in)
Controller weight: 5 kg (12 lbs)

Range

Horizontal envelope: /- 270°
Vertical envelope: 75° to -50°
Minimum working range: 0m
Maximum working range: 70m (230-ft.) diameter

Environmental

Altitude: -700 to 2,450 meters
Humidity: 0 to 95% non-condensing
Operating Temperature: -15°C to 50°C (5°F to 122°F)

Laser Emission

633-635 nm Laser, 1 milliwatt max/cw.
Class II Laser Product

Distance Measurement Performance

Resolution: 0.5µm
Sample rate: 10,000 samples/sec
Accuracy: 10µm 0.4µm/m
R0 Parameter: 10µm

Angle Measurement Performance

Angular accuracy: 18µm 3µm/m
Maximum angular velocity :180°/sec
Optional Precision Level Accuracy: /- 2 arcseconds

Includes;

• Tracker head
• MCU
• MCU to head cable
• Temp sensor
• CAT 6 crossover cable
• Power Cord
• Calibration Stand
• CAM 2 2018 Software and Dongle
• Heavy Shipping Cases
• Brunson folding stand and shipping case

• Availability: 11 In Stock
• Model: X V2
