FARO Vantage Laser Trackers enable you to build and inspect products by measuring quickly, simply and precisely with exceptional portability. The Vantage platform offers comprehensive, large-volume 3D measurement up to 80 meters, streamlining your processes and giving you confidence in your measurement results.

CAPACITY:
WORKING RANGE W/ FARO 1.5" GREEN-RING/BLUE RING SMR.. 114.8 FEET

WORKING RANGE W/ 1.5" & 7/8" IN SMR'S
114.8 FEET

WORKING RANGE WITH MAXIMUM 1/2" IN SMR'S
98.4 FEET

MINIMUM WORKING RANGE
0

ROTATIONAL HORIZONTAL ENVELOPE (INFINITE ROTATION)
360 DEG.

ROTATIONAL VERTICAL ENVELOPE (INFINITE ROTATION)
130 DEG.( 77.9 TO -52.1)

DATA OUTPUT RATE
1,000 MEASUREMENT POINTS/SECOND

DISTANCE RESOLUTION
0.00002"

DISTANCE ACCURACY
0.00063" 0.0000096 IN/FT

MAXIMUM RAIDAL ACCELERATION
82 FT/SEC2

MAXIMUM RADIAL VELOCITY
98.4 FT./SEC

APPROXIMATE DIMENSIONS
9.4" WIDE X 16.4" HIGH

APPROXIMATE WEIGHT
29.5 LBS.

EQUIPPED WITH:

DYNAMIC 6 DEGREES OF FREEDOM IADM IP52 LASER TRACKER WITH PRECISION LEVEL & INTEGRATED WEATHER STATION
AC POWER CALBE FOR VANTAGE E,S, LASER TRACKER
NOTEBOOK-POWER USER, 64 BIT
CAM2 PROBING ADDITION
1.5" SMR HEAVY DUTY BREAK RESISTANT
STAND-PORTABLE FOLDING STAND, SOFTCASE
TARGE TOOLING KIT-INCHES, SOFT CASE
TRACKER 6PROBE KIT
6PROBE TOOLING KIT-ADVANCED
COMPLETE CARE-LT VANTAGE V2/3-Y3
CASE-PORTABLE TRIPOD HARD CASE
10M POWER/COMMUNICATION CABLES
3M AIR TEMPERATURE SENSOR
MANDREL
POWER SUPPLY
UTILITY SOFTWARE
CAM2 MEASURE VERSION 10.7 SOFTWARE
TRI-POD BASE
CASE

Also you can check product : Used Leica Absolute Tracker AT402 Laser Tracker - Sale !!

• Availability: 6 In Stock
• Model: Vantage E6
• Brand:
